Product Details
| Configuration |
| Bore Size d1 (small diameter) |
|
| Bore Size d2 (large diameter) |
|
| Outer Diameter D (in) |
1.890 |
| Length (in) |
3.150 |
| L1 (in) |
1.06 |
| Mass (lb) |
1.653 |
| Max. Rotation Speed (min-1) (rpm) |
7,000 |
| Misalignment Angular (degrees) |
3 |
| Misalignment Axial (in) |
+ 1.6 |
| Misalignment Parallel (in) |
0.035 |
| Torque Max. (ft lb) |
59 |
| Nominal Torque (ft lb) |
29.5 |
